INDUSTRIAL PANEL PC

INDUSTRIAL PANEL PC, developed by Pro-Log Aquadata using the latest
technologies, has a wide range of applications from Rivers to Dams, from
Underground Wells to Lakes, from Irrigation Canals to Flood Control, from
Meteorological Stations to Hydro Power Plants, from Wind Power Plants to
Solar Power Plants, from Waste Water Management to Coastal Design,
from Environmental Studies to Agricultural Irrigation Areas, from Automated
Irrigation Systems to SCADA systems.

Pro-Log has the ability to make decisions using all sensors connected to it.

It saves the information it reads to the memory in the desired format at the
desired recording interval and can transfer this data directly via the built-in
4.5G modem module. In addition, Pro-Log analyzes the data obtained from
sensors with artificial intelligence and can generate detailed reports.
With functions such as both DataLogger and 4.5G modem, Pro-Log meets
various needs in a single device.

Pro-Log's connectivity features are quite diverse. The added sensors support

different connection protocols such as RS-485, RTU Modbus, 4-20mA.

Another prominent feature is the built-in GSM modem module and LoRa module,

which enables Pro-Log to seamlessly communicate with IoT devices without a
physical connection, issue remote commands and transfer sensor data to the
SCADA system. This allows Pro-Log to instantly monitor, collect data and quickly
manage sensors located in remote areas. This flexible communication capability
offers users a wide range of applications, easily adapting to various industrial needs.

COMPATIBILITY

• Computer, mobile (Android and IOS) and Web compatible with.
• Fully integrated with all SCADA systems with RS 485 ModBus RTU.
• Fully integrated with DSİ GÖZBIS system.

PHYSICAL PROPERTIES

• 1 USB 3.0
• 1 USB 2.0
• 1 Type-C
• 1 RJ45
• 1 HDMI
• 1 Wi-Fi
• 6 Digital Inputs
• 4 Digital/4...20 mA Outputs
• 5 Analog/4...20 mA Inputs
• 1 Internal Battery Voltage Read Input
  (Onboard)
• 1 Charge Voltage Read Input
  (Onboard)
• 1 Solar Panel Voltage Reading Input
• 1 Internal LoRa
• 1 Internal Batarya
• 1 RS232 (Modbus RTU etc.)
• 2 RS-485 (Modbus RTU etc.)
• 1 Bluetooth 5.0
• 1 External SD Card Input
• 1 3.5 mm Speaker Input
• 3 Antenna Inputs (SMA connector)
• 1 RJ9H
• 1 SIM Card Input
• 5” LCD Touch Screen
• 1 Internal Front Camera
• 1 Internal GSM


CAMERA MONITORING SYSTEM

Camera surveillance systems allow you to monitor your installed

Current Monitoring Stations live

in high quality (1080p).
