Water Level Indicator
Used to determine water level in water wells
- Info
- Techspecs
- Gallery
- Documents
WATER LEVEL INDICATOR (ELECTRICAL CONTACT METER)
| Water Level / Total Depth Measurement Electrical contact meters are portable, quick and easy to use. In drilling wells, underground water pipes, reservoirs, lakes and pump experiences underground water level and total depth measurements. |
| Working Principle The electronic tip in the probe of the devie; When it comes into contact with the water surface, the jeweler gives an audible and illuminated warning. The level is read in meters (m) and centimeters (cm) over the graduated measuring cable. |
3V DC, 2piece AA size pen battery. Each one 1.5V
CablePolyamide coated steel tape with transparent polyethylene covering over 2 tinned copper conductors on both sides of the steel strip. Cable Metrics Dimensions in millimeters (mm), centimeters (cm) and decimeters (dm) on the yellow steel strip are colored in black and meters (m) in red. Probe Made of chrome-nickel plated brass. Diameter 14mm, length: 140mm. Custom size probe is manufactured according to the order. Cable Construction Transparent, hard plastic and heat resistant. Power Supply Measurement Range Models are available in lengths of 20m, 50m, 100m, 150m, 200m, 300m and 500m. Sensitivity 100m cable length--- smaller than 1 cm
